Specs For Cummins Marine Engines
Application: Marine
Power: 150/155 hp @2800 rpm
Torque Range: nm[ft-lb] 380[280] – 597[440]
Engine Weight:Â kg(lb) 360(794)
Standard Engine Oil Capacity: 10.4 liters [11 qt]
Cooling System Capacity: 17.4 liters [18.4 qt]
Application: Marine
Power: 210/220 hp @2600 rpm
Torque Range: nm[ft-lb] 542[400] – 827[610]Â
Engine Weight: kg(lb) 465(1025)
Standard Engine Oil Capacity: 15 liters [16 qt]
Cooling System Capacity: 20.6 liters [21.6 qt]Â
Application: Marine
Power: 260/270 hp @2600 rpm
Peak Torque @1600 rpm: nm[ft-lb] 922 [680]Â
Engine Weight: kg(lb) 465(1025)
Standard Engine Oil Capacity: 15 liters [16 qt]
Cooling System Capacity: 20.6 liters [21.6 qt]Â
Application: Marine
Power: 315/330 hp @2800 rpm
Peak Torque @2000 rpm:Â nm[ft-lb] 931[687]Â
Engine Weight:Â kg(lb) 465(1025)Â
Standard Engine Oil Capacity: 15 liters [16 qt]
Cooling System Capacity: 20.6 liters [21.6 qt]Â
Application: Marine
Power: 355/370 hp @3000 rpm
Rated Torque: nm[ft-lb] 842 [620]Â
Peak Torque @2200 rpm: nm[ft-lb] 992 [732]Â
Engine Weight: kg(lb) 465(1025)
Standard Engine Oil Capacity: 15 liters [16 qt]
Cooling System Capacity: 20.6 liters [21.6 qt]
Application: Marine
Power: 425 hp @3000 rpm
Peak Torque @2000 rpm: nm[ft-lb] 1220 [900]Â
Engine Weight: kg(lb) 658(1450)
Standard Engine Oil Capacity: 15.1 liters [16 qt]
Cooling System Capacity: 25 – 27 Liters [26-28.5 qt]
Application: Marine
Power: 480 hp @3400 rpm
Peak Torque @2200 rpm: nm[ft-lb] 1274 [940]Â
Engine Weight: kg(lb) 658(1450)
Standard Engine Oil Capacity: 15.1 liters [16 qt]
Cooling System Capacity: 25 – 27 Liters [26-28.5 qt]
Application: Marine
Power: 250 hp @2600 rpm
Rated Torque: nm[ft-lb] 676 [499]Â
Peak Torque @1600 rpm: nm[ft-lb] 983 [725]Â
Engine Weight: kg(lb) 658(1450)
Standard Engine Oil Capacity: 15.1 liters [16 qt]
Cooling System Capacity: 26.5 liters [28 qt]
Application: Marine
Power: 305 hp @2600
Rated Torque: nm[ft-lb] 824 [608]
Peak Torque @1700: nm[ft-lb] 1174 [866]Â
Engine Weight: kg(lb) 658(1450)
Standard Engine Oil Capacity: 15.1 liters [16 qt]
Cooling System Capacity: 26.5 liters [28 qt]
Application: Marine
Power: 380 hp @3000 rpm
Rated Torque: nm[ft-lb] 890 [657]Â
Peak Torque @2000rpm: nm[ft-lb] 1335 [985]Â
Engine Weight: kg(lb) 658(1450)
Standard Engine Oil Capacity: 15.1 liters [16 qt]
Cooling System Capacity: 26.5 liters [28 qt]
Application: Marine
Power: 425 hp @3000 rpm
Rated Torque: nm[ft-lb] 995 [734]Â
Peak Torque @2000 rpm: nm[ft-lb] 1424 [1050]Â
Engine Weight: kg(lb) 658(1450)
Standard Engine Oil Capacity: 15.1 liters [16 qt]
Cooling System Capacity: 26.5 liters [28 qt]
Application: Marine
Power: 255 hp @1800 rpm
Peak Torque: nm[ft-lb] 1193 [880]Â
Engine Weight: kg(lb) 712(1570)
Standard Engine Oil Capacity: 21.9 liters [23.2 qt]Â
Cooling System Capacity: 28.9 liters [30.5 qt]Â
Application: Marine
Power: 350 hp @ 2500 rpm
Peak Torque: nm[ft-lb] 1125 [830]Â
Engine Weight: kg(lb) 712(1570)
Standard Engine Oil Capacity: 21.9 liters [23.2 qt]Â
Cooling System Capacity: 28.9 liters [30.5 qt]Â
Application: Marine
Power: 430/450 hp @2600 rpm
Rated Torque: nm[ft-lb] 1178 [869]Â
Peak Torque @1800 rpm: nm[ft-lb]1395[1029]Â
Engine Weight: kg(lb) 712(1570)
Standard Engine Oil Capacity: 21.9 liters [23.2 qt]Â
Cooling System Capacity: 28.9 liters [30.5 qt]Â
Application: Marine
Power: 500–600 hp
Rated Torque: 1408 [1038]Â
Peak Torque @1800 rpm: nm[ft-lb] 1800 [1327]Â
Engine Weight: kg(lb) 896(1975)
Standard Engine Oil Capacity: 21.6 liters [5.7 gal]Â
Cooling System Capacity: 25-29 liters [6.5-7.75 gal]
Application: Marine
Power: 285 hp @1800 rpm
Peak Torque @1400 rpm: nm[ft-lb] 1332 [983]Â
Engine Weight: kg(lb) 977(2153)
Standard Engine Oil Capacity: 25.4 liters [26.8 qt]
Cooling System Capacity: 29.3 liters [31 qt]
Application: Marine
Power: 330 hp @1800 rpm
Peak Torque @1400 rpm: nm[ft-lb] 1553 [1145]Â
Engine Weight: kg(lb) 977(2153)
Standard Engine Oil Capacity: 25.4 liters [26.8 qt]
Cooling System Capacity: 29.3 liters [31 qt]
Application: Marine
Power: 405 hp @2100 rpm
Peak Torque @1400 rpm: nm[ft-lb] 1619 [1194]Â
Engine Weight: kg(lb) 977(2153)
Standard Engine Oil Capacity: 25.4 liters [26.8 qt]
Cooling System Capacity: 29.3 liters [31 qt]
Application: Construction
Power: 330 hp @2100
Peak Torque @1400 rpm: nm[ft-lb] 2305 [1170]Â
Engine Weight: kg(lb) 1188(2620)
Standard Engine Oil Capacity: 32.9-36.7 liters [33.8-38.8 qt]
Cooling System Capacity: 36 liters [38 qt]
Application: Construction
Power: 400 hp @2100 rpm
Peak Torque @1400 rpm: nm[ft-lb] 1898 [1400]Â
Engine Weight: kg(lb) 1188(2620)
Standard Engine Oil Capacity: 32.9-36.7 liters [33.8-38.8 qt]
Cooling System Capacity: 36 liters [38 qt]
Application: Marine
Power: 670@2300 rpm
Rated Torque: nm[ft-lb] 2046 [1509]Â
Peak Torque @1700 rpm: nm[ft-lb] 2373 [1750]Â
Engine Weight: kg(lb) 1188(2620)
Standard Engine Oil Capacity: 32.9-36.7 liters [33.8-38.8 qt]
Cooling System Capacity: 36 liters [38 qt]
Application: Commercial, Recreational Marine Propulsion and Auxiliary Engines
Power Range: 450 – 700 hp
Peak Torque Range @1500 rpm: nm[ft-lb] 2137 [1576] – 4985 [3676]
Engine Weight : kg(lb) 2073(4570)
Standard Engine Oil Capacity: 32-72 liters [8.5-19 gal] Â Please Note: There are several different engine oil capacities based on the oil pan your KTA19 has. Stated is the estimated range, your capacities may vary. Also, if the engine has a rear gear train, then you must add 7.6 liters [2 gal] to the oil pan capacity.Â
Cooling System Capacity: 32.2 liters [34 qt]
Application: Marine
Power: 640 hp @1800 rpm
Rated Torque: nm[ft-lb] 2532 [1867]Â
Peak Torque @1500 rpm: nm[ft-lb] 2830 [2087]Â
Engine Weight : kg(lb) 2073(4570)
Standard Engine Oil Capacity: 32-72 liters [8.5-19 gal] Â Please Note: There are several different engine oil capacities based on the oil pan your KTA19 has. Stated is the estimated range, your capacities may vary. Also, if the engine has a rear gear train, then you must add 7.6 liters [2 gal] to the oil pan capacity.Â
Cooling System Capacity: 32.2 liters [34 qt]
Application: Marine
Power Range: 850 – 1500Â hp @1800 rpm
Rated Torque: nm[ft-lb] 4747 [3501]Â
Peak Torque @ 1500 rpm: nm[ft-lb] 5210 [3843]Â
Engine Weight : kg(lb) 4218(9300)
Standard Engine Oil Capacity (sub-base Sump): 87-114 liters [23-30 gal]
Standard Engine Oil Capacity (double deep front/center sump): 140 – 166 liters [37-44 gal]
Standard Engine Oil Capacity (double deep rear/center sump): 140-166 liters [37-44 gal]
Cooling System Capacity: 118 – 155 liters [31.2-41 gal]
Application: Marine
Power (overload): 1430 hp @1800 rpm
Power (prime power): 1300 hp @1800 rpmÂ
Power (continuous): 1040 hp @ @1800 rpm
Rated Torque (overload): nm[ft-lb] 1066 [1440]Â
Rated Torque (prime power): nm[ft-lb] 969 [1300]Â
Engine Weight : kg(lb) 4218(9300)
Standard Engine Oil Capacity (sub-base Sump): 87-114 liters [23-30 gal]
Standard Engine Oil Capacity (double deep front/center sump): 140 – 166 liters [37-44 gal]
Standard Engine Oil Capacity (double deep rear/center sump): 140-166 liters [37-44 gal]
Cooling System Capacity: 118 – 155 liters [31.2-41 gal]
Application: Commercial and Recreational Marine Propulsion Engines  Â
Power Range: 1180 – 1875Â hp @1800 rpm
Peak Torque Range @1800 rpm: nm[ft-lb] 5603 [4132] – 6747 [4976]Â
Engine Weight : kg(lb) 5166(11,389)
Standard Engine Oil Capacity (sub-base Sump): 171-246 liters [45-65 gal]
Standard Engine Oil Capacity (Deep Center Sump): 174 – 204 liters [46-54 gal]
Standard Engine Oil Capacity (Front and Front/Center Sump): 171-246 liters [45-65 gal]
Cooling System Capacity: 197-227 liters [52-60 gal]
Application: Commercial and Recreational Marine Propulsion Engines  Â
Power Range: 500-800 hp
Peak Torque Range @1800 rpm: nm[ft-lb] 1978[1459] – 3164[2334]Â
Engine Weight : kg(lb) 2189(4825)
Standard Engine Oil Capacity: 84.4 liters [89.2 qt]
Cooling System Capacity: 97 liters [102.5 qt]
